Wiring Duct



線槽圖紙

Wide slot/finger design provides greater sidewall rigidity and canbe used with a wide range of wire bundle sizes。
Certificates:UL:E306674 CE:EN50085 RoHS,REACH。
Made of rigid PVC
UL Recognized continuous use temperature: 50°C (122°F)
UL94 Flammability Rating of V-0
Provided with mounting holes
Available color:gray.white.blue.black and other special colors
Work Temperature:-40°C to 65°C
Special length come with MOQ request
Comment:gray is the common color, other color need more MOQ
Standard Length:2M/PCS




Item No.

W*H

Slot
width
Q

Finger
width
P

Wire
capability
/2.0sp

PACK/M

GrayWhiteBlueBlack
VDR1616FVDR1616WVDR1616EVDR1616B16*168103~10pcs

300M

VDR1520FVDR1520WVDR1520EVDR1520B15*208.5128~12pcs260M
VDR2020FVDR2020WVDR2020EVDR2020B20*208.51210~20pcs240M
VDR4020FVDR4020WVDR4020EVDR4020B40*2081212~28pcs140M
VDR1525FVDR1525WVDR1525EVDR1525B15*258105~15pcs260M
VDR2025FVDR2025WVDR2025EVDR2025B20*258105~15pcs200M
VDR2525FVDR2525WVDR2525EVDR2525B25*2581010~25pcs200M
VDR3025FVDR3025WVDR3025EVDR3025B30*2581012~28pcs160M
VDR5025FVDR5025WVDR5025EVDR5025B50*2581020~30pcs100M
VDR1530FVDR1530WVDR1530EVDR1530B15*308108~15pcs180M
VDR2030FVDR2030WVDR2030EVDR2030B20*3081225~35pcs160M
VDR2530FVDR2530WVDR2530EVDR2530B25*3081225~35pcs160M
VDR3030FVDR3030WVDR3030EVDR3030B30*3081225~35pcs140M
VDR4030FVDR4030WVDR4030EVDR4030B40*3081230~40pcs100M
VDR3333FVDR3333WVDR3333EVDR3333B33*3381235~45pcs160M
VDR2035FVDR2035WVDR2035EVDR2035B20*3581230~40pcs100M
VDR3535FVDR3535WVDR3535EVDR3535B35*3581235~45pcs112M
VDR5035FVDR5035WVDR5035EVDR5035B50*3581240~60pcs88M
VDR2040FVDR2040WVDR2040EVDR2040B20*4081216~22pcs110M
VDR2540FVDR2540WVDR2540EVDR2540B25*4081220~25pcs112M
VDR4040FVDR4040WVDR4040EVDR4040B40*4081260~70pcs100M
VDR6040FVDR6040WVDR6040EVDR6040B60*40812100~115pcs68M
VDR8040FVDR8040WVDR8040EVDR8040B80*40812120~135pcs48M
VDR10040FVDR10040WVDR10040EVDR10040B100*40812120~135pcs32M
VDR2545FVDR2545WVDR2545EVDR2545B25*4581220~25pcs104M
VDR3345FVDR3345WVDR3345EVDR3345B33*4581240~55pcs108M
VDR4545FVDR4545WVDR4545EVDR4545B45*4581260~70pcs72M
VDR6545FVDR6545WVDR6545EVDR6545B65*45812110~120pcs56M
VDR2050FVDR2050WVDR2050EVDR2050B20*5081218~28pcs120M
VDR2550FVDR2550WVDR2550EVDR2550B25*5081220~30pcs100M
VDR3050FVDR3050WVDR3050EVDR3050B30*5081225~40pcs84M
VDR3550FVDR3550WVDR3550EVDR3550B35*5081240~60pcs80M
VDR4050FVDR4050WVDR4050EVDR4050B40*5081260~70pcs68M
VDR4550FVDR4550WVDR4550EVDR4550B45*5081270~80pcs60M
VDR5050FVDR5050WVDR5050EVDR5050B50*5081280~90pcs60M
VDR5550FVDR5550WVDR5550EVDR5550B55*5081285~95pcs48M
VDR6050FVDR6050WVDR6050EVDR6050B60*50812100~120pcs48M
VDR8050FVDR8050WVDR8050EVDR8050B80*50812160~180pcs40M
VDR10050FVDR10050WVDR10050EVDR10050B100*50812200~250pcs26M
VDR12555FVDR12555WVDR12555EVDR12555B125*55812220~270pcs20M
VDR2060FVDR2060WVDR2060EVDR2060B20*6081235~45pcs100M
VDR2560FVDR2560WVDR2560EVDR2560B25*6081240~50pcs100M
VDR3060FVDR3060WVDR3060EVDR3060B30*6081260~80pcs80M
VDR3560FVDR3560WVDR3560EVDR3560B35*6081290~105pcs78M
VDR4060FVDR4060WVDR4060EVDR4060B40*60812100~115pcs60M
VDR4560FVDR4560WVDR4560EVDR4560B45*60812110~125pcs30M
VDR5060FVDR5060WVDR5060EVDR5060B50*60812120~135pcs60M
VDR6060FVDR6060WVDR6060EVDR6060B60*60812120~135pcs48M
VDR8060FVDR8060WVDR8060EVDR8060B80*60812180~210pcs36M
VDR10060FVDR10060WVDR10060EVDR10060B100*60812240~290pcs28M
VDR11060FVDR11060WVDR11060EVDR11060B110*60812250~300pcs48M
VDR12060FVDR12060WVDR12060EVDR12060B120*60812260~320pcs48M
VDR15060FVDR15060WVDR15060EVDR15060B150*60812300~360pcs16M
VDR2565FVDR2565WVDR2565EVDR2565B25*6581240~50pcs88M
VDR3365FVDR3365WVDR3365EVDR3365B33*6581240~70pcs80M
VDR4565FVDR4565WVDR4565EVDR4565B45*65812110~120pcs52M
VDR6565FVDR6565WVDR6565EVDR6565B65*65812180~200pcs44M
VDR7265FVDR7265WVDR7265EVDR7265B72*65812180~230pcs42M
VDR5075FVDR5075WVDR5075EVDR5075B50*75812180~210pcs32M
VDR7575FVDR7575WVDR7575EVDR7575B75*75812200~240pcs24M
VDR2580FVDR2580WVDR2580EVDR2580B25*80812100~120pcs72M
VDR3080FVDR3080WVDR3080EVDR3080B30*80812110~125pcs56M
VDR3580FVDR3580WVDR3580EVDR3580B35*80812110~130pcs56M
VDR4080FVDR4080WVDR4080EVDR4080B40*80812140~160pcs48M
VDR4580FVDR4580WVDR4580EVDR4580B45*80812140~160pcs40M
VDR5080FVDR5080WVDR5080EVDR5080B5080812160~180pcs40M
VDR5580FVDR5580WVDR5580EVDR5580B55*80812160~180pcs32M
VDR6080FVDR6080WVDR6080EVDR6080B60*80812180~210pcs32M
VDR8080FVDR8080WVDR8080EVDR8080B80*80812240~290pcs24M
VDR10080FVDR10080WVDR10080EVDR10080B100*80812260~350pcs24M
VDR12080FVDR12080WVDR12080EVDR12080B120*80812280~380pcs16M
VDR14080FVDR14080WVDR14080EVDR14080B140*80812350~450pcs16M
VDR25100FVDR25100WVDR25100EVDR25100B25*100812110~160pcs60M
VDR33100FVDR33100WVDR33100EVDR33100B33*100812130~165pcs44M
VDR40100FVDR40100WVDR40100EVDR40100B40*100812130~175pcs40M
VDR50100FVDR50100WVDR50100EVDR50100B50*100812220~250pcs40M
VDR60100FVDR60100WVDR60100EVDR60100B60*100812240~290pcs32M
VDR70100FVDR70100WVDR70100EVDR70100B70*100812250~310pcs24M
VDR75100FVDR75100WVDR75100EVDR75100B75*100812260~350pcs24M
VDR80100FVDR80100WVDR80100EVDR80100B80*100812260~350pcs24M
VDR100100FVDR100100WVDR100100EVDR100100B100*100812300~400pcs24M
VDR120100FVDR120100WVDR120100EVDR120100B120*100812350~450pcs16M
VDR150100FVDR150100WVDR150100EVDR150100B150*100812400~650pcs16M
VDR200100FVDR200100WVDR200100EVDR200100B200*100812600~800pcs16M
VDR100130FVDR100130WVDR100130EVDR100130B100*130812350~450pcs24M
VDR200150FVDR200150WVDR200150EVDR200150B200*150812900~1200pcs10M










FeaturesAdvantagesBenefits
Wide finger and slot design
Can be used with a wide
range of wire and
Finger 12mm Slot 8 mm,Rigid fingersbundle sizes
Rohs approved
Enviroment-friendly
Material
Approved by EU Rohs,
Compliant with US UL 94V-0,good
inflaming
Eliminates health concerns associated with PVC
that contains lead
Smooth rounded edgesSmooth edges in duct slots and at top of duct fingersProtects hands and wiring/cabling from abrasion
